Pluggable connector, Cross-sectional rating: 2.5 mm2, Color: Green, Current rating: 12 A, Voltage rating (III/2): 320 V, Contact surface: Tin, Contact type: Pin connector, Number of potentiometers: 2-24, Number of rows: 1, Number of digits: 2-24, Connections: 2-24, Series: DB2EKP, Pin pitch: 5.08 mm, Wiring: Screw connection with tab, Screw head size: L slotted, Wire/PCB connection orientation: 0°, Latch: - without latch, mating system: COMBICON DB2EKP, Interlock: without, Mounting: without, Package type: Carton
Advantages
☑Universal connectivity for global use
☑Features pluggable modules for Easy PCB replacement
☑Reverse connector with multiple pin pins provides touch protection for device output or free hanging wire-to-wire connections
☑Combinable with DB2E series connectors
☑Maximum contact force with low ramp-up
