PCB Pluggable Connectors DB2EKB-7.5

Plug-in connector, Nominal cross-section: 2.5 mm2, Colour: green, Nominal operating current: 12 A, Rated voltage (III/2): 630 V, Contact surface: tin, Contact type: hole connector, Number of potentials: 2-24, Number of rows: 1, Number of digits: 2-24, Connection capacity: 2-24, Series: DB2EKB, Pin pitch: 7.5 mm, Wiring method: screw connection with crimp, Screw head size: L slot, Wire/PCB connection direction: -90°, Latch: - latch, Plug-in system: COMBICON DB2EKB, Interlocking: without, Screw connection with crimp, Screw head size: L slot, Wire/PCB connection direction: -90°, Latch: - latch Screw connection with crimp, Screw head size: L slotted, Wire/PCB connection direction: -90°, Closure: - latch, Insertion system: COMBICON DB2EKB, Interlocking: without, Mounting: without, Packing type: carton
